Hood-Type Dishwasher - 50x50 Basket - DIGIT Control Panel
Hood-type dishwasher with electronic control, allowing you to set and monitor rinse and drain times and temperatures.
Through the control panel, you can select one of 4 wash cycles and an automatic drain cycle (with drain pump installed), view tank and boiler temperatures on the display, system Self-diagnosis messages, and the Scheduled Maintenance alert.
Equipped with an easily removable rack support for easy cleaning and a rounded, deep-drawn tank with integral filters to ensure perfect drainage and absolute hygiene.
The “PUSH TO START” cycle start system ensures reduced waste by preventing empty wash cycles.
Thanks to the Thermostop function, washing and rinsing start only once the desired temperature is reached. The double electric peristaltic detergent and rinse aid dispenser, installed as standard, guarantees maximum results from every wash cycle.
Code: X110E
Brand: Compack
| Construction features |
|---|
| Structure in AISI 304 stainless steel |
| Technical sheet | |
|---|---|
| Standard power supply: 400V3N+T / 230V 50Hz | Dimensions cm 62x77x143.5/190h |
| Maximum glass height: 390mm | Maximum plate Ø: 415mm |
| Maximum pot height: 390mm | Bread basket capacity: 40 LT (H=390mm) |
| Trays: GN1/1 | Tank heating element - Tank capacity: 4.5kW - 37lt |
| Boiler heating element - Boiler capacity: 5.4kW - 7.3lt | Pump power: 1.34kW / 1.8Hp |
| Total power / Current: 6.74kW / 16A | Recommended water supply: +55°C |
| Recommended water hardness: 7÷10 °f | Water consumption per cycle (with recommended pressure 2 BAR): 2.0lt |
| Adjustable detergent and rinse aid dispenser: Electric | |
